Logitech Rally Bar and Rally Bar mini in comparison

The all-in-one conference systems from Logitech

Since March 2020, many of us have been in our home offices. Thanks to modern webcams, conference cameras and video conferencing systems , countless online meetings and training sessions have taken place during this time. Along the way, manufacturers have worked diligently on innovations to make our work processes more pleasant and efficient. In the process, Logitech developed a solution that offers us a glimpse of how we will work in the future.

Content

Logitech Rally Bar: How good is the all-in-one video conferencing system really?

We were allowed to exclusively test the Logitech Rally Bar in our house before the official sales launch. In this video, our colleagues show the most important innovations and functions.

Get ready to return to the office with Logitech!

The past months have shown us that working from home works well - but not forever. For the hybrid working that is being implemented in many companies, Logitech has created many solutions that combine the benefits of digital work and being together in person: the Logitech Rally Bar and Logitech Rally Bar mini.

Logitech-Rally-Bar-und-Rally-Bar-Mini-Groessenvergleich
Logitech Rally Bar (top) and Logitech Rally Bar mini (bottom) size comparison

What both systems have in common are the AI technologies (RightSense):

Icon light bulb

RightLight

The lighting conditions are adjusted to make the speaker clearly visible.
Icon Field of view

RightSight

The speaker is focused by the camera.
Icon loudspeaker

RightSound

Ambient noise, such as street noise from outside, is suppressed during a video conference.
Logitech-MeetUp-Konferenzkamera-4K-13MP-30fps-120-FOV-5x-Zoom_(1)

Logitech Rally Bar: The video conferencing system for medium-sized rooms

  • can intelligibly record and fully display up to 12 people.
  • is easy to set up, operate and manage.
  • automatically moves the lens and adjusts the zoom.
  • adjusts to current lighting conditions.
  • suppresses unwanted noise.

Logitech Rally Bar: Key Facts

We have compiled the most important features for you here. You can find all the technical data for the Logitech Rally Bar and the matching accessories in our online shop.

Colours

Graphite and white

Image resolution

4K, 1440p, 1080p, 900p, 720p and SD at 30 frames per second

Integrated microphones

6

Integrated loudspeakers

2

Zoom

15x HD zoom, 5x optical

Total room detection

132.1° horizontal 82.2° vertical

Loudspeaker output

90 dB SPL at 1 W 99 dB SPL at 8.0 W each +/-2 dB at half volume

Audio range

4,5 m

Inputs

1x HDMI, 3x USB 3.0 type A, 1x USB 3.0 type C

Outputs

2x HDMI, 1x external microphone output

Full hard disk encryption

AES128

Data encryption

Symmetrical, PKI

Logitech Rally Bar vs. Logitech MeetUp: The 5 most frequent customer questions

Industry experts will note at this point that an all-in-one system with the Logitech MeetUp conference camera is already available and therefore nothing new. Therefore, we have compared the two systems with the most frequently asked questions from our customers.

Depending on the size of the room and/or the number of people, one system is more suitable for you than the other. To make it easier for you to decide, we have compared the 5 most frequently asked customer questions with the two Logitech video conferencing systems here.

Our customers asked ..
Logitech Rally Bar video conferencing system
Logitech MeetUp conference camera
"How many people are recognisable at the same time?"up to 12 peopleup to 6 people
"What types of rooms is it suitable for?"medium-sized rooms of approx. 20 sqm: e.g. conference rooms, workshop rooms, meeting roomssmall rooms of approx. 16 sqm: e. g. E.g. huddle rooms, small meeting rooms, offices
"Is a USB 3.0 cable included for 4K transmission?"yes, with a cable length of 2.2 metresyes, with a cable length of 5 metres
"Which video conferencing software is it compatible with?"suitable for all common systems: Zoom, Microsoft Teams, pexip, GoToMeeting, RingCentralsuitable for all common systems: Zoom, Microsoft Teams, pexip, GoToMeeting, RingCentral
"How many microphones can be connected?"up to 3 Mic Podsonly one additional Mic Pod


Expert tip: If you have a long and narrow meeting room, you should connect more microphones. You can either mount these on the ceiling or on the conference table.

Logitech Rally Bar mini: The video conferencing system for small rooms

The Logitech Rally Bar mini is the little brother of the Rally Bar. It was launched in mid-2021 and offers an all-in-one solution for small conference rooms with approx. 1 - 6 people.

logitech-rally-bar-mini-grafit

Logitech Rally Bar mini: Key Facts

We have summarised the most important technical data for you here. You can find everything else about the Logitech Rally Bar mini and the matching accessories in our online shop.

Colours
Graphite and white
Image resolution
4K, 1440p, 1080p, 900p, 720p and SD at 30 frames per second
Integrated microphones
6
Integrated loudspeakers
3
Zoom
4x HD zoom
Total room detection
163° horizontal, 110° vertical
Loudspeaker output
90 dB SPL at 1 W 99 dB SPL at 8.0 W each +/-2 dB at half volume
Audio range
4,5 m
Inputs
1x HDMI, 3x USB 3.0 type A, 1x USB 3.0 type C
Outputs
2x HDMI, 1x external microphone output
Full hard disk encryption
AES128
Data encryption
Symmetrical, PKI

Logitech Rally Bar mini vs. Logitech MeetUp: Which system suits you?

Both solutions are basically suitable for smaller conference rooms with few participants (approx. 6 people). But the Logitech Rally Bar mini, as an all-in-one system, offers a few more features than its predecessor.

Our customers asked ..
Logitech Rally Bar mini
Logitech MeetUp
"Is an additional laptop necessary for a video conference?"no, you can start your videoconference in the system (appliance mode)yes, you have to start the videoconference software from your laptop
"What features does the camera offer?"4x HD zoom and an AI viewfinder5x HD zoom and 3 camera settings
"How many microphones are integrated?"6 built-in microphones3 integrated microphones
"How far does the sound reach without additional microphones?"4.5 metres4 metres
"Can additional microphones be connected?"yes, up to 3 Mic Podsyes, one additional Mic Pod


Expert tip: If you have a long and narrow meeting room, you should connect additional microphones. You can either mount these on the ceiling or on the conference table.

Logitech Rally Bar and Logitech Rally Bar mini: set-up and assembly

With the practical plug-and-play system, you do not need to install any additional software to start your video conference. Add to that the appliance mode. This means you don't need to connect a laptop, as popular video conferencing tools are on the Logitech Rally Bar and Rally Bar mini.

Logitech-MeetUp-Konferenzkamera

The Logitech Rally Bar and the Logitech Rally Bar mini can be:

  • stand on a sideboard or shelf
  • mount on the wall (wall bracket required)
  • or mount directly above the display (TV mount required)

Suitable accessories for efficient meetings

With Logitech accessories, you can integrate your Rally Bar and Rally Bar mini perfectly into your meeting room, both visually and technically. In addition to the wall and TV mounts, Logitech offers the proven Mic Pods.

In recent months, digitalisation in Germany has made huge progress. More and more companies realised that efficient working and learning is possible through home office, online meetings and online training. Home office will (hopefully) remain in a hybrid system (= switching between working in the office and from home) in the future.

Let your employees collaborate from anywhere. Logitech can support you in this in your everyday professional life if you want to bring your team together.
